TBS Lucid H7 Stack 8S 60A

The TBS Lucid H7 Stack 8S 60A is a top - notch all - in - one solution. It features a powerful STM32H743VIH6 MCU running at 480MHz, with 1MB RAM and 2MB Flash. The AT7456E OSD Chip and Infineon DPS310 barometer ensure excellent performance. There are 13 PWM output channels, including a dedicated LED pad. Data logging is easy with the MicroSD card slot. It has 7 UARTs, 2 I2C buses, and 1 CAN bus. Six ADC channels handle various analog inputs. Three LED indicators show different statuses. It has a Type - C USB interface. With dual camera input and power control, it offers great flexibility. The ESC uses AlkaMotors32 software, rated at 70A x 4 for 60 seconds and a peak of 85A x 4 for 30 seconds. It supports 3 - 8S Lipo input and bidirectional Dshot 300/600 protocols. The innovative 'Gorilla' mount provides superior power delivery and is great for frame integration.

Using the TBS Lucid H7 Stack 8S 60A is easy. First, connect your power source and make sure it's within the 3 - 8S Lipo input range. Plug in your cameras to the dual camera inputs and select the one you want. Connect your motors to the PWM outputs. For data logging, insert a MicroSD card. When using the ESC, keep in mind the rated and peak current limits. Don't exceed the recommended propeller size. If you use propellers over 7', ensure good airflow. When it comes to maintenance, regularly check the connectors for any signs of wear or damage. Clean the board gently with a soft brush to remove dust. Store it in a dry and cool place when not in use. Also, make sure to update the ESC software regularly for optimal performance.
