T-Motor F55A Pro III 55A 3-8S AM32 4-in-1 ESC

Elevate your flying experience with the T-Motor F55A Pro III 4-in-1 ESC. Boasting TPHR8504 MOSFETs and an STM32G071 microcontroller, this ESC offers top - notch stability and durability. It comes with TVS protection and uses high - quality materials, making it perfect for high - intensity flights. With support for 3 - 8S batteries and a PWM frequency range of 16 - 128kHz, it ensures great motor compatibility. The dual heat sink design effectively keeps it cool. The F55A Pro III redefines performance and reliability, ideal for challenging flights. **Features** - TPHR8504 MOSFETs and STM32G071 MCU - Adjustable PWM frequency - Efficient heat management - Wide voltage support - Excellent performance - Enhanced durability **Specifications** - Mounting Hole: 30.5*30.5mm/M3 - Peak Current: 65A (10 Seconds) - Amperage Meter: 200 - Size: 44*40*7.5mm - Telemetry: Support - Voltage: 3S - 8S Lipo - Firmware: AM32 - Weight: 17.8g - Current: 55A - BEC: No **Includes** - 1x T-Motor F55A Pro III 55A 3 - 8S AM32 4 - in - 1 ESC - 30x30 - 1x 61mm Double - Ended SH1.0 - 10P Silicone Cable - 1x 61mm Single Head SH1.0 - 10P Silicone Cable - 4x High Yellow Shock Absorbing Washer - 4x Low Yellow Shock Absorbing Washer - 1x Capacitor **Browse More** - Browse all T - Motor - Browse all 4in1 ESC - Browse all AIO ESC

Using the T-Motor F55A Pro III 4-in-1 ESC is quite straightforward. First, make sure to connect it correctly to your motor and battery according to the specifications. The mounting holes are 30.5*30.5mm/M3, so you can easily install it in your setup. When powering it on, ensure your battery voltage is within the 3S - 8S Lipo range. For safety, always check the wiring before each flight. Avoid over - current situations as the peak current is 65A for only 10 seconds. The amperage meter can help you monitor the current. In terms of maintenance, keep it clean and dry. The dual heat sink helps with cooling, but if you notice it getting too hot during use, check if there are any blockages. Also, if you need to update the firmware (it's AM32), follow the manufacturer's instructions carefully. This way, you can ensure the long - term performance and durability of your ESC.
