Phaser FPV XT60 iSDT compatible parallel charging board with 40A fuse

Are you on the hunt for an affordable parallel charging board to expand your FPV collection? The Phaser FPV Safe 40A Parallel Charge Board is here to revolutionize your charging experience! It lets you charge four battery packs at once, slashing the charging time significantly. All you need is for the battery packs to have the same cell count and be in a similar state of discharge (within 0.2V). That means you can charge four 3S 2200mAh or larger batteries simultaneously with a standard charger. A standout feature of this board is its 'daisy chain' capability. It comes with 4mm bullet jacks and a balance plug connection, allowing you to link another parallel board to it. This way, you can connect multiple boards with different plug types and charge all your same cell - count batteries at once! The Safe 40A parallel charge board also features replaceable automotive - style fuses to safeguard each circuit, ensuring safe charging up to 40A. Specifications: Product size is 143*68*19mm, output has 6 x XT60, input is XT60, and it has a built - in 40A protection fuse. Package includes 1x XT60 Parallel charging board and 1x Balance extension Lead. You can also browse all LiPo Chargers, LiION Chargers, LiPo Batteries, cables and connectors, and iSDT products.

Using this Phaser FPV XT60 compatible parallel charging board is easy. First, make sure your battery packs have the same cell count and are within 0.2V of each other in terms of discharge state. Connect your battery packs to the output XT60 ports on the board. Then, connect the input XT60 port of the board to your standard charger. When charging, keep an eye on the process. The replaceable automotive - style fuses are there to protect the circuits, but if you notice any issues like overheating or abnormal behavior, stop charging immediately. For maintenance, keep the board clean and dry. If you want to expand your charging capacity, use the 4mm bullet jacks and balance plug connection to 'daisy chain' another board. Remember, always use the correct charger and follow the battery manufacturer's guidelines.
